Eurolite USB-DMX512 PRO Interface MK2

Professional USB DMX Interface for Controlling DMX Devices with a Computer

  • Suitable for a variety of DMX software applications
  • Fully supported by FreeStyler, DMXControl and PC_DIMMER
  • Output of up to 512 DMX channels
  • Stable DMX output thanks to integrated processor
  • Compatible with Windows 7, 8 and 10, Mac OS X and Linux
  • Connections: 3-Pin XLR connector (Neutrik), USB 2.0/ 1.1 B
  • DMX output galvanically isolated against voltage damage
  • Sturdy metal housing
  • Power supply via USB
  • Power supply: 5 V DC via USB
  • Dimensions (L x W x H): 80 x 42 x 50 mm
  • Weight: 350 g
  • Incl. USB cable A/ B
  • Made in Germany

Further Information

Type USB-Interface
Type of construction Desktop
Connection for PC/Ethernet USB
Universes (Outputs) 1
DMX-Output 3-pole XLR female
DMX-Input not supported
RDM-capable No
Internal memory No

These are other customers' choices:

Customers who looked at this item have bought these:

Eurolite USB-DMX512 PRO Interface MK2
63% bought this exact product
Eurolite USB-DMX512 PRO Interface MK2
Available immediately
Available immediately

This item is in stock and can be dispatched immediately.

Standard Delivery Times
77 € Add to Basket
Enttec Open DMX USB Interface
12% bought Enttec Open DMX USB Interface 59 €
Enttec DMX USB Pro Interface
8% bought Enttec DMX USB Pro Interface 138 €
Eurolite USB-DMX512-Interface/Update-Ad
4% bought Eurolite USB-DMX512-Interface/Update-Ad 45 €
Showtec NET-2/3 Pocket
4% bought Showtec NET-2/3 Pocket 166 €
Our most popular Lighting Interfaces and Nodes
36 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.8 /5
  • features
  • quality
Total
features
quality
Awesome little USB-DMX controller
Anoko, 03.10.2020
Using this device, together with the "glight" DMX software, I've been able to control a ~100 LED par lightshow during a big dance competition, and it worked great at all times. It allows proper syncing the light chases/transitions to the music, which is absolutely stunning. The device itself is sturdy and supported by many software tools. I've been involved in finishing the OpenDMX Linux driver for it, so that OpenDMX now supports the device as well.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
features
quality
stanly12, 07.09.2018
work only with freestyler. other aplications are crashing on my PC. each one of this cheap dmx works only with few programs. i did not find any profesional solution in this price level.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
features
quality
Aris P, 17.12.2019
Excellent product, is the 2nd I've bought. I usually work it with notebook with win 10 pro 64bit and freestyler and i am very satisfied, it works like a harm, I've never encounter problems. I highly recommend it.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
de Original review (Show translation)
Unfortunately there was an error. Please try again later.
Total
features
quality
Gutes Produkt...Aber !
andrasar, 08.12.2016
Grundsätzlich handelt es sich bei dem Eurolite USB-DMX512 Pro MKII um ein solides Produkt.

Verarbeitung:
Das Gehäuse ist aus Metall und gut verarbeitet. Der XLR Anschluss ist solide und die USB Buchse ist Standard. Wenn man kein all zu schlechtes USB Kabel verwendet, hält das auch für den Hausgebrauch. Der USB-Anschluss ist nicht extra geschützt oder verriegelt, sodass bei argen Road-Attacken hier die Verbindung recht schnell weg ist (weil Kabel ab).

Funktion:
Das MKII macht was es soll. 1 DMX Universum übertragen. Das es kein DMX-In gibt, sollte man sich vorher in der Beschreibung durchgelesen haben und sich später nicht überrascht geben.

Wenn man eine überschaubare Anzahl an Fixtures steuert ist das MKII Interface eine gute und runde Sache.
Und das für überschaubares Geld.

Hat man aber mehr Geräte zu steuern, die gegebenenfalls auch noch unterschiedlich auf Stop- und Startbits reagieren, stößt das MKII an seine Grenzen.
Die Geräte fangen dann teilweise an nicht mehr in Time sondern mit diversen Latenzen zu arbeiten.
Das fällt vor allem bei bewegtem Licht auf.
Ich hatte 7 Scanner und 8 MovingHeads plus diverse LED PAR dran. das wurde dem MKII zu viel.
Sanfte Bewegungen der MH waren nur noch bedingt möglich. Hier wären einstellbare Parameter schön gewesen.

Aber: Dies gibt es ja auch, halt nicht solide für unter 100 EUR.

Hier sollte man sich dessen also bewusst sein.


Kompatibilität:
Das MKII läuft aktuell NICHT auf DMX Control 3.0
Mit Freesytler x2 läuft es wie beschrieben.

Man sollte eventuell die Kompatibilitätslisten der diversen Applikationen studieren.


Fazit:
Gutes Produkt für jeden, der ein paar Lampen und wenige Wackelkannen und auch nur 1 DMX Universum steuern möchte. Dafür ist es klasse und kann empfohlen werden.
