Behringer WING
48-Channel Full Stereo Digital Mixer
- New Routing approach due to a focus on sources rather than channels
- Fully compatible with the Behringer X32/Midas M32 consoles and stage boxes
- Vintage emulation of EQs, compressors and gates available in all of the 40 stereo inputs
- 40 Stereo inputs
- 8 Stereo Aux inputs
- 28 Busses: 16 stereo Aux, 8 stereo Matritzen and 4 stereo mains
- 24 Faders in 3 fully programmable sections
- 10" Touch Display with adjustable angle
- Programmable custom control section
- 8 Midas pro microphone preamps
- 8 Analog Midas line outputs
- 8 Aux inputs
- 6 Aux outputs and 2 monitor outputs: 6,3 mm jack symmetrical mono
- 2 Headphone outputs
- 3 AES50 Ports: 48x48 Channels per port - cable length up to 80 meters
- MIDI I/O
- 2 Programmable GPIOs
- 48x48 Channel USB Interface
- Expansion slot including WING-LIVE card
- 64x64 Channel SD Recorder/Player
- Additional cards (Dante, MADI, Soundgrit) available (optional)
- StageCONNECT 32 Channel port for personal monitoring
- 16 FX Engines: 8 premium and 8 standard
- 6 Band EQ on the inputs
- 8 Band EQ on the outputs
- Dimensions (HxBxD): 201 x 870 x 575 mm
- Weight: 24 kg
Further Information
| Buses | 28 |
|---|---|
| Inputs | 18 |
| Channels (max. amount) | 48 |
| DCA (Digitally Contr. Amp.) | Yes |
| Card Slot (external) | Yes |
| Touchscreen | Yes |
| Offline Editing | Yes |
| Demountable Stagebox | Yes |
| External Power Supply | No |
| Port For Ext. Power Supply | No |
| 19" Rack Unit | No |
| Built in Audio player | Yes |
