Tascam DP-24 SD

24-Track Digital Portastudio

  • Portable multi-track recorder with 12 mono tracks and 6 stereo tracks
  • Simultaneous recording of 8 and simultaneous playback of 24 tracks
  • Recording to SD card
  • Sampling rate: 44.1 / 48 kHz
  • Resolution: 16/24 bit
  • 19 Faders
  • 3-Band EQ on each input and each track
  • Dedicated knobs for EQ, pan and effect send
  • Colour display
  • Peak memory in level meters on the display
  • Auto Punch function
  • 8 Virtual tracks per track for alternate Takes
  • Up to 99 location marks per song
  • Dynamic effects for inputs (limiter, compressor, noise suppression, exciter)
  • Multi effect for guitar
  • Effects of the mixture (reverb, delay, stereo chorus) and mastering tools (EQ, multi band compressor, normalizer)
  • Chromatic tuner
  • Integrated metronome
  • File transfer via USB 2.0
  • 8 Line/microphone inputs: XLR / TRS combo jack
  • Phantom power for all inputs
  • Input 8 can be switched to Hi-Z instrument input
  • 2x Line outputs: RCA (L/R stereo)
  • 2x Monitor outputs: 6.3 mm jack (L/R stereo)
  • 2 FX sends: 6.3 mm jack
  • Stereo Headphone Jack: 6.3 mm jack
  • Connection for optional foot-switch RC-3F
  • Dimensions (W x H x D): approx. 514 x 104 x 340 mm
  • Weight: 5.8 kg
  • Incl. power supply and SD card

Further Information

Number Of Tracks 24
Simultaneous Recording: Amount Of Tracks 8
Effects Yes
Storage Medium SD Card
Phantom power Yes
XLR Connectors 8
Jack Connectors 8
RCA Connectors Yes
MIDI Interface None
USB connection Yes
Digital Connections None
Miscellaneous Connectors Foot Switch
Headphone connection Yes

Come up with your own creative bundle and save

If you order this product together with others as part of a bundle, you can save up to 5 % additionally!
Tascam DP-24 SD + the t.bone SC 1100 + Cordial CAM 9 BK +
8 more
Configure bundle now
starting from 599 €

This product is currently sold out

These are other customers' choices:

Zoom LiveTrak L-12
21% bought Zoom LiveTrak L-12 599 €
Tascam DP-32 SD
16% bought Tascam DP-32 SD 575 €
Tascam Model 12
14% bought Tascam Model 12 595 €
Rode Rodecaster Pro
8% bought Rode Rodecaster Pro 511 €
Our most popular Multitrack Compact Studios
130 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.6 /5
  • handling
  • features
  • sound
  • quality
Total
handling
features
sound
quality
Great standalone alternative to DAW
svenakos, 06.03.2021
Build quality

Robustly built, very clearly laid out.
As far as build is concerned, the only thing I'm not crazy about is the power adapter which seems a bit flimsy (the plug is replaceable and not very sturdy).

Usability

Workflow is as I expected having, in ancient times, worked with a Yamaha MT4X portastudio, and a great relief compared to the inspiration-killing sadness that is a mouse and keyboard and having to wrestle with drivers, windows updates and popups. Do read the well written user manual before use though - this machine does have relatively many options and you shouldn't expect to be able to work with it without any reading.

Sound

The 24 bit DACs should provide enough headroom to avoid ugly digital clipping with a clear margin.
Compared to my Focusrite Sapphire 2i2, the input sensitivity on the Hi-Z (guitar) input is actually sensible, meaning a P-90 singlecoil cannot overload the preamp with the input gain turned all the way down.
The built-in guitar amp simulator sounds weedy and is only good for hearing something resembling an electric guitar while recording a DI signal. I wouldn't use it for any serious recording, ever.

In summary, a good sounding, well built machine which, after just a bit of time studying how it works, is great fun to use and does not get in your way.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
handling
features
sound
quality
The best we have used.
CoorEast, 08.03.2017
We have tried a few recording devices but this is definitely the best so far (BR1600CD, US1800). In fact, we will be sticking with this one as it offers all we need; multiple-simultaneous inputs for transferring to a computer and simple mixing facilities for rough mixing on the desk.

It has more features than we need but some of the controls have left us searching through the manual as they are not overly intuitive - adding compression on a particular input channel for example - but these would probably be easily remembered if we used it more often. The large-ish display is a nice touch and the menus are simple enough to navigate. The displays show all you need.

The tracks are easily moved to a computer, but can be brought back once mixed for the mastering features which, we think, are better than in our software.

It is robust enough but we did get a decent Thomann case for it - just in case.

Using SD-cards is handy too as these are very inexpensive and a new one can be used for each song. As we used inexpensive SD cards recording at 32-bit we didn't have any of the reported issues associated with the higher sampling rate using cheap SD cards.

Value for money is outstanding. We paid more than this for our first BR-532 (which we still use).
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
handling
features
sound
quality
A fine way of working
Dan_Studioman, 20.08.2017
After having worked with DAW-software for a long time now, I thought it was about time to add this machine to my setup. I like the way it looks, I like the functions and I like the way it sounds. It is easy to use, just allow yourself the patience to work your way through the manual and you'll be fine. Working with a DAW has its pros and cons, the cons for me being spending way too much time editing, tweaking and what not, which was sometimes almost sucking the human feel right out of things. The Tascam is a great recording device to indeed have that 'live feel' to your recording sessions. For me, it brought about fresher ways of approaching the arrangement of a song. Great value for the money, so go for it!
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
handling
features
sound
quality
Home recording heaven
Nick the Bluesman, 07.04.2021
After the demise of my old four track porta studio I decided on the Tascam DP-24 SD after reading other reviews on the product.
Once you get through all the jargon in the manual it's quite easy to use and the record and playback are very good. For multi track recording and overdubbing it's also quite easy. I would recommend this product for any musician for either home or live recording.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
469 €
Free shipping incl. VAT
In stock within 4-5 weeks
In stock within 4-5 weeks

This item is expected back in stock soon and can then be shipped immediately.
