Swisson XSW-TR-3B W-DMX Box

DMX / Wireless Transceiver for Truss-Mounting

  • Combines a wireless DMX transmission with a splitter
  • Can work both as DMX transmitter and DMX receiver
  • The DMX splitter functionality is always available, regardless of whether the device is configured as a sender or as a receiver
  • If only the splitter function is used, the radio part can be switched off
  • Several radio links can be set up in parallel so that several DMX512 lines (Univers) are transmitted
  • Several receivers can be connected to one transmitter
  • Different topologies can be built with the same XSW components
  • Wireless DMX transmitter
  • Wireless DMX receiver
  • DMX splitter
  • DMX Booster
  • Optically isolated
  • Internal power supply
  • Voltage: 100 - 240V, 50 / 60Hz
  • Connection: fixed cable with open ends
  • Protocol: DMX 512 / Wireless Solution
  • Signal distribution: 1 x DMX in (3-pin) to 5 x DMX out (3-pin), wireless rx + tx
  • Metal housing
  • Dimensions (W x D x H): 215 x 125 x 45 mm
  • Weight: 0.7 kg
  • Colour: Red / black

Dalsze informacje

Type Splitter
Distribution-type 1in5
Input 5-pole XLR
3-pole XLR Outputs Yes
5-pole XLR Outputs No
19"-capable No
RDM-compatible No
WDMX-capable Yes
Wyświetl wariacje tego produktu
Swisson XSW-TR-3B W-DMX Box
Swisson XSW-TR-3B W-DMX Box

DMX / Wireless Transceiver for Truss-Mounting Combines a wireless DMX transmission with a splitter, Can work both as DMX transmitter and DMX receiver, The DMX splitter functionality is always...

Swisson XPD-28-5R RDM & DMX-Splitter
Swisson XPD-28-5R RDM & DMX-Splitter

Swisson XPD-28-5R A/B RDM & DMX Splitter; RDM-capable DMX splitter and booster; Distributes and amplifies DMX signals from two inputs to eight outputs; this allows the 32-device limit of the DMX...

Swisson XSW-TR-5R W-DMX 19" 1HE
Swisson XSW-TR-5R W-DMX 19" 1HE

DMX / Wireless Transceiver for Rackmount Combines a wireless DMX transmission with a splitter, Can work both as DMX transmitter and DMX receiver, The DMX splitter functionality is always available,...

633 € 2 712,46 zł
darmowa wysyłka, zawiera podatek VAT.

Cena w PLN podana jest w celach orientacyjnych

Na tel./email
Na tel./email

Termin dostawy nie został jeszcze określony W celu uzyskania dalszych informacji prosimy o kontakt.
