Behringer X32

638

32-Kanaals 16-Bus Digitaal Mengpaneel

  • 32 XLR Mic/Line-ingangen
  • 8 Stereo FX returns
  • 16 Mix-bussen
  • 6 Matrix-bussen met insert
  • 6 Mute-groepen
  • 8 DCA-groepen
  • 16 XLR-uitgangen
  • 6x AUX In via 6.3 mm Jack (optioneel 2 via RCA)
  • 6x AUX Out via 6.3 mm Jack (optioneel 2 via RCA)
  • AES/EBU stereo digital output
  • 2 Koptelefoonuitgangen via 6,3 mm Jack
  • Stereo Monitor/Control Room-uitgang met dim- en monofunctie
  • 32In/32out USB-audio-interface
  • Motor fader: 100 mm
  • 7'' TFT kleurendisplay
  • LCD-display per kanaal
  • 4-Bands volledig parametrische EQ per kanaal
  • Instelbare delays in alle kanalen
  • Virtueel effects-rack met 8 FX slots
  • Ingebouwde stereo USB recorder
  • Op afstand bedienbaar met USB of ethernet
  • Compatibel met het Behringer P-16 personal monitoring system
  • Volledige MIDI-implementatie
  • Afmetingen (B x D x H): 900 x 550 x 230 mm
  • Gewicht: 20,0 kg
  • Bijpassende uitbreidingskaart: SD Record art. 448412 (niet bij de levering inbegrepen)
  • Bijpassende case: art. 281791 (niet bij de levering inbegrepen)
  • Bijpassende cover: art. 487523 (niet bij de levering inbegrepen)
Leverbaar sinds Augustus 2012
artikelnummer 259395
verkoopseenheid 1 stuk
Max.number of input channels 32
Microphone Inputs 32
Analog Line Inputs 32
Analog Line Outputs 16
Analog in/ out with plug-in card expandable Yes
Digital Inputs None
Digital Outputs AES
Digital in-/ outputs expandable Yes
Word Clock No
Motorfader Yes
Computer interface USB, Ethernet
MIDI-interface Yes
User Interface Physical/remote
Number of faders 25
DSP Input channels 32
DSP Output Channels 24
Busses 16
Mic Preamp 32
Mono-Line Input 6
Stereo-Line Input 0
Physical outputs 22
Digital stagebox connection AES50
Ethernet Ethernet
Hotspot No
Multitrack Record Yes
Special Features Compatible with BEHRINGER P-16 Personal Monitoring System, 32 in / 32 out FW Interface
Soundcard interface USB-B
integratated Player/Rec via USB/SD stereo
Recorder Format WAV
Scribble Strips 1
RTA Yes
FX Processor 8
31 Band EQ 8
Delay Input 1
Delay Output 1
Matrix 6
DCA/VCA Groups 8
Midi Connector Midi-Din
Sample rate 48 kHz
Monitor Apps 1
Separate Personal Monitor system Optional
Expansion Card slots 1
Digital ADAT Optional
Digital SPDIF No
Digital AES3/ASESEB Yes
Digital MADI Optional
Digital Dante Optional
110V capable 1
Case Included
19" Rackmount No
Height 200 mm
Width 900 mm
Depth 528 mm
Weight 20,6 kg
Toon meer
€ 2.222
alle prijzen incl. btw
direct leverbaar
direct leverbaar

Dit product is op voorraad en kan direct verzonden worden.

Informatie over de verzending
Levering zonder verzendkosten tot ongeveer Zaterdag, 12.10.
1

638 Klantenbeoordelingen

4.8 / 5

U moet ingelogd zijn om producten te evalueren.

Note: Om te voorkomen dat evaluaties gebaseerd zijn op roddel, geruchten of heimelijke advertentie staan wij op onze website alleen evaluaties toe van daadwerkelijke gebruikers die het geevalueerde product bij ons gekocht hebben.

Na inloggen vindt u alle producten die u kunt evalueren ook onder “Product evalueren” in uw klantencentrum.

bediening

features

geluid

afwerking

303 Recensies

N
Fijne Mixer
Nielsdries 03.05.2020
Hier heb ik het op geleerd dus een streepje voor op de rest. Functies zijn heel handig geplaatst, Geluid kan beter maar voor een live set is de technicus de enige die dat gaat horen. Firmware upgrades zijn erg makkelijk uit te voeren en goed ontworpen.
bediening
features
geluid
afwerking
0
0
Evaluatie melden

Evaluatie melden

ds
top tafel
de speld 01.03.2024
wij gebruiken deze tafel met name voor toneel en musical voorstellingen. Het show control gedeelte is top om diverse scene's te programmeren.
Eenmaal verdiept in de tafel is het gebruik redelijk eenvoudig
bediening
features
geluid
afwerking
0
0
Evaluatie melden

Evaluatie melden

A
Behringer X32
Anoniem 18.05.2016
Schitterdende digitale tafel met oneindig veel mogelijkheden, levering met UPS zeer snel in huis!
Om niet te vergeten de goede stevige verpakking van Thomann.
Hier gaan we veel plezier van hebben!!
bediening
features
geluid
afwerking
0
2
Evaluatie melden

Evaluatie melden

google translate gb
Helaas is er een fout opgetreden, probeert u het a.u.b. later nogmaals.
M
Review X32
Moggy624 13.06.2013
I was impressed with this board for its spec. and price, and the fact that it could run on Cat 5 to a stage box. The fact that Midas had also helped in the design of the pre amps and the manufacturing process was another plus. So it was bought together with the S16 and the flightcase (Also reviewed).

We mainly use the X32 at different venues for musical theatre so the extra channels (32) were a plus over the Presonus 24.4.2 (24) which we previously used and still own. I had considered buying another X32 to provide us with 64 channels for the large shows we do with Orchestras. We currently feed that into the Presonus which is used alongside the X32.

I tried to use the X32 for a multi track recording of our latest show, but the software (Studio One 2 Pro on a Mac Book Pro) stated that the external hard drive I was recording too was not fast enough to record all 32 tracks. I changed to 24 tracks but still got the error. However, you can get an instant 2 channels mix using the inbuilt recorder. There is also the facility to play back wav files via a USB stick but I would like to see that further expanded to allow playlist to be set up to auto play or play a playlist rather than one track at a time.

I hadn't experienced the lag on the same external hard drive (Toshiba PA4144E-1HB5) with the Presonus 24.4.2 using their software "Capture", So it may well be I'll have to wait till the hard drives using "Thunderbolt" become cheaper.

The Midas pre amps have a nice analogue sound to them when compared with the Presonus 24.4.2 which can sometimes sound "hard" and "crisp".

I've found the X32 FX's to be varied and well thought out and the re-verbs on vocals are really nice. If you own the "Waves plug ins" there is also a way to use them through the board using a DAW. (See YouTube)

The DCA#s are great for controlling groups of faders and if set up correctly can minimise the need to keep changing to other layers.

I loved using the mixer when it was working, unfortunately, my board has developed a fault after approx 21 shows, (Outputs 1 to 8 are not outputting any sound). It's not a major problem for me at the moment as we can use the outputs 9 to 16, but for more complicated sets ups this is going to be a problem).

So it will be a call the Thomann tomorrow to test how good their support is. (I may report what happens in a later post)

The fact that it has a 3 year warranty was a plus point when buying it considering Behringer's past reputation for quality and poor support.

The Behringer web site community forum is very helpful for anyone using the board and there is plenty of help if needed and there are plenty of YouTube tutorials to get you started. (Check out Drew Brashler KD7QCU on YouTube he's a wiz and explains his tutorials in easy terms).

The fact that you can control the board by Ipad or computer is a plus point, I was able to feed the fold back monitors which on stage. This is also helpful when listening to your mix from different areas of the Theatre as some venues don't have the sound booth in the central position.
bediening
features
geluid
afwerking
20
1
Evaluatie melden

Evaluatie melden

Geschikt van YouTube
