Universal Audio Apollo Twin X Duo

57 ratings

Watching

10 x 6 Thunderbolt 3 Audio Interface

With UAD-2 DUO processor for almost latency-free recordings via plug-in emulations of classic compressors, EQs, tape machines, microphone preamps and guitar amplifiers
24 Bit / 192 kHz AD / DA converter
2 Unison microphone preamps
Phantom power: +48 V
Integrated talkback microphone
Dynamic range: 127 dB
Monitor functions with controls for Mono, Mute, DIM and ALT
Design: Desktop
Includes Realtime Analogue Classics Bundle for Mac OS and Windows

Connections:

2 Microphone / line combo inputs: XLR / 6.3 mm jack
Hi-Z instrument input: 6.3 mm jack
2 Line outputs: 6.3 mm jack
2 Monitor outputs: 6.3 mm jack
ADAT / SPDIF input optically
Stereo headphone output: 6.3 mm jack
Thunderbolt 3 connector (Thunderbolt cable not included)
Input for external power supply

Further Information

Recording / Playback Channels	10x6
Number of Mic Inputs	2
Number of Line Inputs	2
Number of Instrument Inputs	1
Number of Line Outputs	4
Headphone Outs	1
Phantom Power	Yes
Number of S/PDIF Connectors	1
Number of ADAT Connectors	1
AES/EBU Connectors	0
Number of MADI Connectors	0
Ethernet	0
Other Connectors	No
MIDI Connectors	No
Word Clock	No
Max. Samplerate	192 kHz
Max. Resolution in Bit	24 bit
Bus-Powered	No
Incl. Power Supply	Yes
Windows Thunderbolt driver	Yes
Thunderbolt Version	3
Width in mm	160 mm
Depth in mm	149 mm
Height in mm	66 mm

57 Customer Ratings

5

51 Customers

51 customers have given this product a 5-star rating.

Of these, 43 customers have written no texts or given their feedback in another language.
4

3 Customers

3 customers have given this product a 4-star rating.

Of these, 3 customers have written no texts or given their feedback in another language.
3

1 Customer

One customer has given this product a 3-star rating.

No customer has written a text about this; or they have written a text in a different language.
2
1

2 Customers

2 customers have given this product a one-star rating.

Of these, 2 customers have written no texts or given their feedback in another language.

4.8 /5

handling
features
sound
quality

Excellent product! (Switching from Scarlet 2i2 2nd generation)

brunoooo, 23.11.2020

Great product, quality, and sound are great. Love the feel of the knob, mono function, and 2nd monitor output.
Included plugins are OK, for 14 plugins I got, I will only use 3 of them hence I am not using bass amps, preamps, etc. Would be happier if I received a higher version of Autotune instead of those amps.
Another thing, it does not come with a thunderbolt cable.
All in all, if you want to have a really quality product which is also designed astonishingly, I recommend it!

Helpful · Not helpful · Report

Do you believe this rating to be inaccurate or unacceptable for some reason?

Please give us the reason for your assessment in the following text box and – if possible – your e-mail address for further questions. Send report

I Need More DSP!

EQNX, 15.04.2020

I was using Quad MKII and decide to buy this Thunderbold Duo and of course just problem with not enough DSP for producing or mixing tracks for me if you work not more than 20 channel this will be enough but when projects are getting more channels and you need to use good compressors or effects that DSP will be not enough and UAD plugins just works on DSP power. so im thinking to get satellite already. and also if you need more channel for send and return things externally go for more cause there is just 2 real input in the same time
you will need to buy another ADAT interface to expand it digitally if needed. But at the end of the day im very happy with my purchase you can do really good sound with this card and unison plugins most if you tracking your synth or sounds externally. this one is the best for startup

Helpful · Not helpful · Report

Do you believe this rating to be inaccurate or unacceptable for some reason?

Please give us the reason for your assessment in the following text box and – if possible – your e-mail address for further questions. Send report

WOW

ben sherwood, 22.04.2020

amazing bit of kit only uses thunderbolt 3 so make sure to buy the right cable as its not provided by UAD! oh well
cool feature has a integrated talk back mic very essential for home studio set ups with a separate vocal/recording room...

Helpful · Not helpful · Report

Do you believe this rating to be inaccurate or unacceptable for some reason?

Please give us the reason for your assessment in the following text box and – if possible – your e-mail address for further questions. Send report

Nice product with 1 gripe

IanLanzarote, 14.08.2020

Product itself is excellent. The quality of the build is outstanding and it has an abundance of features. The buttons have a great feel to them and it looks amazing next to my iMac Pro. My only gripe is that it seems to need their proprietary software running to be able to use it with Logic Pro. If it could interface directly, that would be amazing.

Service from Thomann was first class. Order arrived 8 days before the projected delivery date.

Highly Recommended.

Helpful · Not helpful · Report

Do you believe this rating to be inaccurate or unacceptable for some reason?

Please give us the reason for your assessment in the following text box and – if possible – your e-mail address for further questions. Send report
