HK Audio Elements E110 Sub A

Active 10" Subwoofer

  • From the Elements-System
  • Built-in 600 Watt Class-D Power amplifier (1x 250 W for Sub 10 Ohm)
  • 1x 300 W for Top 8 Ohm
  • 45 - 150 Hz
  • RMS-Limiter
  • Subsonic Filter
  • Parallel port for E435 mid / high unit or E110 SUB passive
  • 2x E-Connect System Flange
  • Stackable
  • Dimensions: 36 x 48 x 46 cm
  • Weight: 19 Kg

Further Information

Height in mm 300 mm
Width in mm 460 mm
Depth in mm 480 mm
Weight in kg 19 kg
RMS Power (W) 600 W
Multi Cannel Power Amp Yes
Woofer Size 10"
Number of Woofers 1
High Cut Fixed
Stand mount flange Special
Color Black
Wheels No
25 Customer Ratings
  • 5
  • 4
  • 3
  • 2
  • 1
4.7 /5
  • features
  • handling
  • sound
  • quality
Total
features
sound
quality
handling
Key unit of HK Elements system
31.03.2015
There are more and more 'stick' loudspeaker systems coming on to the market. Sound can only be a personal choice but the HK Elements system is still the most elegant, versatile (in its modular additions) and easy to set up.

The E110 contains a 10 inch driver and amplifiers to power this and either another passive 10 inch speaker or 2 mid-high units. The mid-high units can be connected via an EP45 pole containing all the connections. No wires are visible and the pole can be adjusted for height.

More bass can be generated if the E110A is placed on its side and 2 sockets enable vertical or horizontal positioning. The bass is a nice punchy hi-fi sound rather than trouser flapping bass. There is no control of sound built into the unit which makes it less versatile than some competitors.

2 E110A units and 4 mid-high units struggle to provide room filling sound but are ideal for weddings or small parties for up to 100 people. For larger functions an extra pair of bass speakers is essential. This makes the system expensive against other sound solutions but the portability, convenience and sound quality may outweigh this consideration.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
features
sound
quality
handling
Crazily light
Philippe599, 04.06.2013
I did a lot of research looking for a sub that I could lift in and out of the car without giving myself a hernia... These HK subs are small, they sound amazing and they are half the weight of anything else. I haven't tried the element top units, we use these with some QSC K8's and the whole system sounds amazing. Get the HK covers to keep them looking nice
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
Total
features
sound
quality
handling
LF is go
Owen L., 27.08.2014
Will these sound like a full sized 2 x 15" sub being driven by a 2Kw amp? Obviously not. Do the fill out the bottom end very nicely and punch way above their weight? Yes, thank you very much. On their own these are not going to melt the earth but as part of a balanced system they are surprisingly beefy and deliver a satisfying Low Frequency experience giving the whole Elements system a rich bottom end extension which enable the listener to hear the full range of music being presented - both live bands and pre-recorded stuff. I use 4 in a stack in a 500 seater hall doing low to medium volume stuff. The real bass end is mainly 5 string bass guitar and Electric Drum Kit and the stack deals with these with ease and authority. There is no obvious point where the cabs just decide that the notes are too low and they will not bother. I really like them :). As I said earlier, they are never going to sound like the bottom end of a full arena rig. That is not their job. They do what they are designed to do very well indeed.
Helpful · Not helpful · Report
Report rating…

Do you believe this rating to be inaccurate or unacceptable for some reason?

Send report
de Original review (Show translation)
Unfortunately there was an error. Please try again later.
Total
features
sound
quality
handling
Souverän – ausbaufähig - gut
Stefan853, 16.12.2012
Weil ich an die Grenzen meines bisherigen Monitorsystems, zum Nachbearbeiten von Mitschnitten von Live-Übertragungen für ein Radio aus Kirchen gelangte, machte ich mich auf die Suche nach einem Alleskönner der auch einige Male im Jahr für Beschallung taugen sollte. Das Audiomaterial das von den Boxen reproduziert werden soll, reicht von Sprache bis Orgelkonzert und Messe mit Chor und Orchester mit Solisten aus großen und kleinen Kirchen.
In die engere Wahl kamen zwei Beschallungssysteme:
HK Elements, Acoustics One
LD Maui 11,
und ein Nahfeldmonitor:
DYNAUDIO BM 12A

1. Die Verbindung von Beschallung und Studiomonitoring schaffte auch ich nicht.
2. HK Elements ist ein robustes tourtaugliches Beschallungssystem, das modular aufgebaut, vielseitig kombinierbar und erweiterbar ist, wobei die Komponenten eindeutig und akustisch aufeinander abgestimmt sind und auf mehreren Ebenen Line oder LS aktiv und passiv verbunden werden können.
Die Verarbeitung ist sauber und zweckentsprechend elegant. So klein und leicht wie möglich, so groß wie nötig.
3. Die Basis, die Bassbox liefert Frequenzen ab 45 Hz. Der eingebaute Verstärker hat keine Einstell- oder Anpassmöglichkeiten außer der Anpassung der Anzahl der eingesetzten Topteile. E-Connect, der Anschlußpunkt für die Tops, ist an zwei Stellen vorhanden, so kann der Quader stehend oder liegend verwendet werden.
Der Bass kommt ausgewogen proportioniert und ist klar durchgezeichnet. Wenn auch der Tiefpunkt für den Orgelbass bei 20 Hz ansetzen sollte, ist dieser kleine Abstrich nur von geübten Ohren, im Vergleich mit dem Original (selten möglich) zu hören.
4. Die Topteile, Mid/High-Unit E 435 sind technisch einwandfrei und durchdacht gestaltet und bringen die Töne in kraftvoller Präsenz, fast schon ein wenig hart in der Klarheit. Eine leichte Überbetonung in der Mitte bei ca. 800- 1200 Hz bringt durchaus etwas Wärme hebt aber möglicherweise Geigentöne über den Orchesterverbund heraus.
5. Achtung: Die Tops haben eine sehr saubere Abstrahlcharakteristik, die im Nahbereich unter 3 m Hörabstand zu groben Fehleinschätzungen führen kann. Das sollten sie besonders beim Probehören beachten. Mit anderen Worten, die Hörposition geringfügig ändern kann Klänge erschließen oder verbergen.
HK Elements, Acoustics One
Modular, kombinierbar, ausbaufähig mit geringer Mittenbetonung, beschallt souverän kleine und große Räume mit Musik und Sprache. Ich werde damit auch den Monitorbedarf abdecken.

Den Vergleich mit den anderen Systemen können sie in meinen Bewertungen dieser Produkte nachlesen.
