12-Voice Polyphonic Analog-Hybrid Aynthesizer
- Binaural analog signal path
- 2 Digital oscillators (FPGA based)
- Oscillator 1 with Sine, Sawtooth, Square, Triangle, Noise and Wavetable
- Oscillator 2 with Sine, Sawtooth, Square, Triangle, Noise and Pulse-Width Modulation
- Oscillator synchronization and cross modulation available
- Analog 24 dB low-pass filter with resonance
- Static high-pass filter and switchable overdrive
- Analog VCA
- 2 ADSR Envelopes
- LFO with extended frequency range (0.05 Hz - 20 kHz) and keyboard tracking for FM sounds
- Flexible modulation matrix for further sound design possibilities
- Arpeggiator and 64-step sequencer with MIDI sync
- Delay and Chorus effects
- Control section with assignable Bender
- Portamento fader and Octave elector
- 49-Key Fatar keyboard with Velocity and Aftertouch
- Stereo output: 2 x 6.3 mm jack
- Stereo headphone output: 6.3 mm jack
- Audio input: 1 x 6.3 mm jack
- MIDI: In/Out/Thru
- Sustain and Expression pedal inputs: 2 x 6.3 mm jack
- USB-B port
- Dimensions (W x D x H): 830 x 350 x 90 mm
- Weight: 8 kg
- Colour: Black
- Suitable case: Art. 518091 (not included)
available since
August 2020
Item number
471405
sales unit
1 piece(s)
Number Of Keys
49
Touch-Sensitive
Yes
Aftertouch
Yes
Split Zones
Yes
Modulation Wheel
Yes
Number of simultaneous Voices
12
Sound Engine
Digital Analog Hybrid
MIDI interface
1x In, 1x Out, 1x Thru
Storage Medium
Internal
USB-port
Yes
Effects
2
Arpeggiator
Yes
Number of Analog Outputs
2
Digital Output
No
Display
No
Pedal Connections
1x Pedal, 1x Sustain
Dimensions
830 x 350 x 90 mm
Weight
8,0 kg
