12-Voice Polyphonic Analog-Hybrid Aynthesizer
- Binaural analog signal path
- 2 Digital oscillators (FPGA based)
- Oscillator 1 with Sine, Sawtooth, Square, Triangle, Noise and Wavetable
- Oscillator 2 with Sine, Sawtooth, Square, Triangle, Noise and Pulse-Width Modulation
- Oscillator synchronization and cross modulation available
- Analog 24 dB low-pass filter with resonance
- Static high-pass filter and switchable overdrive
- Analog VCA
- 2 ADSR Envelopes
- LFO with extended frequency range (0.05 Hz - 20 kHz) and keyboard tracking for FM sounds
- Flexible modulation matrix for further sound design possibilities
- Arpeggiator and 64-step sequencer with MIDI sync
- Delay and Chorus effects
- Control section with assignable Bender
- Portamento fader and Octave elector
- 49-Key Fatar keyboard with Velocity and Aftertouch
- Stereo output: 2 x 6.3 mm jack
- Stereo headphone output: 6.3 mm jack
- Audio input: 1 x 6.3 mm jack
- MIDI: In/Out/Thru
- Sustain and Expression pedal inputs: 2 x 6.3 mm jack
- USB-B port
- Dimensions (W x D x H): 830 x 350 x 90 mm
- Weight: 8 kg
- Colour: Black
- Suitable case: Art. 518091 (not included)
available since
August 2020
Item number
471405
sales unit
1 piece(s)
Number Of Keys
49
Touch-Sensitive
Yes
Aftertouch
Yes
Split Zones
Yes
Modulation Wheel
Yes
Number of simultaneous Voices
12
Sound Engine
Digital Analog Hybrid
MIDI interface
In, Out, Thru
Storage Medium
Internal
USB-port
Yes
Effects
2
Arpeggiator
Yes
Number of Analog Outputs
2
Digital Output
No
Display
No
Pedal Connections
1x Pedal, 1x Sustain
Dimensions
830 x 350 x 90 mm
Weight
8,0 kg
