Sennheiser ew IEM G4 Twin A-Band


Evolution Wireless In Ear System

  • Consists of 2 x UHF bodypack receiver (EK IEM G4), 9.5" transmitter (SR IEM G4) and 2 x IE4 earphones
  • Stereo / focus / mono modes
  • Up to 1680 frequencies in 42 MHz switching bandwidth
  • 20 Channel banks each with up to 16 presets
  • Up to 16 compatible channels
  • Frequency response 25 to 15,000 Hz
  • Frequency transmission via infrared interface
  • Pocket receiver with charging contacts for optional rechargeable battery BA 2015 (NiMH)
  • Pilot tone
  • Autotune to find free frequencies
  • Audio Gain includes 60 dB
  • 4-Digit battery indicator on the transmitter and receiver
  • HDX compander
  • OLED display with NF level and channel display
  • 3.5 mm jack for earphones
  • Adjustable limiter
  • Switchable transmission power 10/30/50 mW
  • WSM support (Ethernet interface for Frequency Management)
  • Adjustable 6.3mm headphone jack on the transmitter
  • 1 x BNC antenna socket
  • Inputs 2 x Jack / XLR female balanced combo
  • Power supply 10.5 - 16 V DC
  • Includes power supply NT 2-3 CW
  • 2 Earphones IE 4
  • 4 x 1.5V battery
  • Rack kit GA 3 for 19" installation included
  • Frequency range A-band: 516 - 558 MHz
available since April 2018
Item number 436954
sales unit 1 piece(s)
Switchable Frequencies Yes
Mono/Stereo Stereo
Limiter Yes
Incl. Earpieces Yes
Frequency from 516 MHz
Frequency to 558 MHz
Show more
Free shipping incl. VAT
In stock within 6-8 weeks
In stock within 6-8 weeks

This item is expected back in stock soon and can then be shipped immediately.

Standard Delivery Times

Information on the supported frequency ranges

Here you can see which frequencies are supported by this wireless system and the countries in which these frequencies are allowed in the future for wireless applications.

All information is without guarantee

3 Customer ratings

2 Reviews

google translate de
Unfortunately there was an error. Please try again later.
Sehr gutes und professionelles IEM System
ReinholdA 07.06.2018
Geniales Teil, robust gebaut, verständliche Menü-Führung und kinderleichter Einbau in ein 19Zoll Rack. Schneller Sync mit dem Bodypack.
Keine Aussetzer mehr bei Live-Gigs. Die mitgelieferten In-ears sollte man natürlch gegen etwas Hochwertiges tauschen. Ansonsten alles super !
Achtung: Für das Betreiben des "A"-Bandes braucht es eine entsprechende Urkunde von der BundesNetzAgentur.


google translate es
Unfortunately there was an error. Please try again later.
Peor sonido que la serie G3
Ottox 01.06.2019
Parece una desmejora en la calidad del sonido
