Blackmagic Design Video Assist 7" 3G

Blackmagic Design Video Assist 7" 3G; portable video monitor with dual SD card recorder, scope display and viewfinder in one; also with higher quality recording codecs on board and adds a larger screen to any SDI and HDMI camera; four built-in scopes, improved focus aid, a tally indicator and 3D LUTs; supports formats up to 1080p/60; connectors: SDI video inputs: 1; SDI video outputs: 1; SDI rates: 270 Mbit; 1.5G, 3G; HDMI video inputs: 1; HDMI video outputs: 1; Analogue audio inputs: 2 balanced mini-XLR inputs with phantom power; Analogue audio outputs: 1 x 3.5mm headphone jack; Built-in speaker: 1 mono; Screen dimensions: 7 inch with 1920 x 1200 pixels; Screen brightness: 310 nits; SDI audio inputs: 16 channels embedded in SDI; SDI audio outputs: 16 channels embedded in SDI; HDMI audio inputs: 8 channels embedded in HDMI; HDMI audio outputs: 8 channels embedded in HDMI; Remote control: 1 x 2.5 mm LANC socket for record start/stop; SD interface: dual SD slots for UHS-I cards; memory type: SD cards of types SDXC UHS-I and SDHC UHS-I; supports the following SD cards: DS, HS, SDR12, SDR25, DDR50 and SDR104; computer interface: 1 USB-C port for initial setup, software updates and software control via Video Assist Utility Blackmagic Video Assist '' 3G; SDI video standards: SD video standards: 525i/59.94 NTSC; 625i/50 PAL; HD video standards: 720p/50; 720p/59.94; 720p/60 1080p/23.98; 1080p/24; 1080p/25; 1080p/29.97; 1080p/30; 1080p/50; 1080p/59.94; 1080p/60 1080PsF/23.98; 1080PsF/24; 1080PsF/25; 1080PsF/29.97; 1080PsF/30 1080i/50; 1080i/59.94; 1080i/60; SDI conformity: SMPTE 259M, SMPTE 292M, SMPTE 296M, SMPTE 425M; support for SDI metadata HD RP188; Audio sample rate: Standard television sample rate of 48 kHz and 24 bits; Video sample rate: 4:2:2 YUV; Colour accuracy: 10 bits; Colour space: REC 601, REC 709; Multi-rate support: SDI and HDMI switch between 270 Mbps, 1.5 Gbps and 3 Gbps; HDMI video standards: SD video standards: 525i/59.94 NTSC; 625i/50 PAL; HD video standards: 720p/50; 720p/59.94; 720p/60 1080p/23.98; 1080p/24; 1080p/25; 1080p/29.97; 1080p/30; 1080p/50; 1080p/59.94; 1080p/60 1080i/50; 1080i/59.94; 1080i/60; HDMI colour accuracy: 10 bits; Supported codecs: ProRes 422 HQ / ProRes 422 / ProRes 422 LT / ProRes 422 Proxy / DNxHD 220x / DNxHD 145 / DNxHD 45 / DNxHD 220x MXF / DNxHD 145 MXF / DNxHD 45 MXF; Scopes: Waveform, RGB parade, vectorscope, histogram; Display modes: Scopes with picture-in-picture or as superimposed overlay with adjustable opacity; Power supply: 1 external 12 V power supply unit with adapters suitable for all countries included; operable with Sony-compatible NP-F batteries (batteries not included); dimensions (WxHxD): 193 x 130.5 x 37 mm; weight: 0.825 kg; note: copy protection: copy-protected HDMI sources cannot be recorded via the HDMI input. Always check the copyright before recording or distributing content

Free shipping incl. VAT
Delivery date unknown
Delivery date unknown

This item has sold out and has been re-ordered. Unfortunately, our supplier cannot guarantee delivery within the next three months. We recommend that you choose a suitable alternative from our store.

Standard Delivery Times
Share This Product
Your Contacts
Phone: +49-9546-9223-45
FAX: +49-9546-9223-443
Phone: +49-9546-9223-30
FAX: +49-9546-922328
