Behringer X32 Compact Stagebox f.Bundle
Bundle offer comprising
Behringer X32 Compact
- Digital Mixer
- 16 XLR Mic/ line Inputs
- 8 Stereo FX Returns
- 16 Mix buses
- 6 Matrix buses with insert
- 6 Mute groups
- 8 DCA groups
- 8 XLR Outputs
- 6 AUX In: 6.3 mm Jack (optionally 2 via RCA)
- 6 AUX Out: 6.3 mm Jack (optionally 2 via RCA)
- AES/EBU Stereo digital output
- 2 Headphone outputs: 6.3 mm Jack
- Stereo monitor/ control room output with dim function
- 32 In/ 32 out USB audio interface
- 100 mm Motor fader
- 7" TFT colour display
- LCD Display per channel
- 4-Band full-parametric EQ per channel
- Adjustable delays in all channels
- Virtual effect rack with 8 FX slots
- Built-in stereo USB recorder
- Remote control via ethernet
- Compatible with the Behringer P-16 personal monitoring system
- Full MIDI implementation
- Dimensions (H x W x D): 21.3 x 63.1 x 51.2 cm
- Weight: 15.5 kg
- Suitable expansion boards: Dante: Art. 334096, Madi: Art. 337831
Behringer S16
- Digital Stagebox
- With 16 Inputs and 8 Outputs
- AES50 network (Klark Teknik)
- Up to 100m of networking capability via CAT-5e cable (not included in delivery)
- 7-segment LED displays
- Direct P-16 Monitor port
- Dual ADAT outputs
- MIDI In/Output
- USB connector for system updates via PC
- Format: 19" / 2HE
- Mounting depth: 21 cm
- Distance of the metal handles to the front: 2,2 cm
Flyht Pro Mixercase Behringer X32Compact
- Flight Case
- Custom-made flight case for the Behringer X-32 Compact
- Made from 10 mm birch plywood
- Black coated
- Aluminium edges: 30 x 30 mm
- Foam padding
- 4 Butterfly latches
- Steel ball corners
- 12 cm Cable channel at the back
- Device can be operated from inside the case
- External dimensions (W x D x H): Approx. 684 x 660 x 305 mm
pro snake CAT6E Cable 30m
- CAT6E Cable
- Length: 30 m
- Extremely robust and flexible cable for live studio applications
- 2x RJ 45 Yongsheng plugs (Brand of Neutrik)
- Can be used in D-Format sockets
- 7 mm PVC jacket
- Conductor diameter: 0.565 mm (pure copper)
- 4-Pair 23 AWG CAT6 SFTP cable
- Colour: Black
available since
August 2019
Item number
473060
sales unit
1 piece(s)
User Interface
Physical/remote
Number of faders
17
DSP Input channels
32
Mic Preamp
16
Physical outputs
14
Digital stagebox connection
AES50
Hotspot
No
Multitrack Record
Yes
integratated Player/Rec via USB/SD
stereo
19" Rackmount
No
DSP Output Channels
24
Busses
16
Mono-Line Input
6
Stereo-Line Input
0
Ethernet
Ethernet
Soundcard interface
USB-B
Recorder Format
WAV
Scribble Strips
1
RTA
Yes
FX Processor
8
31 Band EQ
8
Delay Input
1
Delay Output
1
Matrix
6
DCA/VCA Gruppen
8
Midi Connector
Midi-Din
Sample rate
48 kHz
Monitor Apps
1
Separate Personal Monitor system
Optional
Expansion Card slots
1
Digital ADAT
Optional
Digital SPDIF
No
Digital AES3/ASESEB
Yes
Digital MADI
Optional
Digital Dante
Optional
110V capable
1
Case
Included
Height
215 mm
Width
625 mm
Depth
510 mm
Weight
15,4 kg
